Specifications :
| Technical Index | |
| Laser Type | Hermetic and detached CO2 laser tube |
| Laser Power | 60W/80W/100W/120W/150W |
| Cutting Speed | 0-36000mm/min |
| Engraving Speed | 0-64000mm/min |
| Resetting Position Accuracy | 0.01mm |
| Resolution Ratio | 0.025mm |
| Highest Scanning Precision | 25000DPI |
| Graphic Format | AI, CDR, BMP, JPG, DST, PLT, DXF, DWG, TIFF, PSD |
| Supported Software | CorelDraw, PhotoShop, AutoCad etc. |
| The Smallest Cutting Characters | Character 2.0mm*2.0mm English 1.0mm*1.0mm |
| Power Supply | 220V/50HZ |
| Whole Power | <1000W |
| Operating Temperature | 0C-45°C |
| Operating Humidity | 5-95% (Free of condensed water) |
*speed calculatiuon on 10ft roll under Stander conditions
The Manufacturer reserve the rights to change the specification & features without prior notice.
Features :
- 65 DSP high speed processor : Adopts 64 DSP high speed control system, which highly improves the data processing speed and stability.
- Support of USB and U disc : USB connect to the machine or U disc independently, which can use only one computer to control many laser machines.
- Storage Function : Large storage function, which can store hundreds of files for offline operation.
- Real Time Regulation (RTR) : Users can regulate the laser power according to needs to improve the engraving effect.
- Easy operation : Control panel and software have English language so that satisfies the needs of different customers.
- Rotary clamp for engraving (optional) : Can engrave not only sheet, but also materials and cylinders such as pencil vase, flute, bottle, etc.
Application Of Industry :
- Advertising signs and logos, craft and gift, crystal ornaments, paper cutting techniques, printing plate, leather, clothing, embroidery, decoration, frame products.
Application Material :
- ABS double color sheet, acrylic sheet, wood, glass, paper, leather, cloth, plastic, rubber, marble, ceramic tiles and other nonmetalic materials.
